功能特点
◇ Electrical oscillating knife cutting head, strong strength, high vibration frequency, up to 22,000 times per minute;
◇ High-resolution short-focus direct projection, 1:1 pattern output for clearer and more intuitive workflow.
◇ The independent anti-shock design projection frame avoids the influence of the machine on the projection during the production process, making the projection more stable.
◇ Personalized interactive work function, making typesetting, cutting and receiving at the same time, maximizing equipment efficiency.
◇ The highly integrated multi-function head can simultaneously cut, punch, draw and mark.
◇ The self-developed automatic typesetting cutting system maximizes the need for automatic typesetting and cutting of leather and PU, and improves the utilization of leather materials efficiently, while eliminating the worries of software upgrades.
◇ Support international DXF, HPGL format, avoid compatibility problems between different software, and make the workflow more simplified.
| CNC Leather Cutting Machine JD-AS-L Series Technical Parameters Standard Table | |||
Technical Parameters/Model | JD-AS-1410L | JD-AS-1813L | JD-AS-2516L |
Operating Characteristic | 1400mm*1000mm | 1800mm*1300mm | 2500mm*1600mm |
Cutting Speed | 800mm/s-1200mm/s | ||
Cutting Thickness | 0.5-6mm | ||
Cutting Material | Leather, artificial leather, cardboard, rubber sheet, gray board, composite material, gasket, white cardboard | ||
Tool | Rotating the cutter head, oscillating head, punching | ||
Drive Motor | Servo Motor | ||
Available Pen Type/Number | Ordinary pen, oil pen, ball pen, silver pen / 8 groups of different strokes, half knife, knife set full | ||
Way for Fixing Material | Vacuum adsorption | ||
Repeat Accuracy | ≦0.05mm | ||
Transmission Interface | Ethernet port | ||
Command System | HP-GL & GP-GL | ||
Transmission Material | Linear guide, imported synchronous belt | ||
Voltage and Power | AC 220V 380V ± 10%, 50HZ; Total Power 6kw; Fuse Size 6A | ||
Oscillating Knife Head | Oscillation Knife Head motor 22000 rpm,Electric and pneumatic head optional | ||
