Jindex electronic screen film cutting machine JD-ASF series
Type:
Electronic screen film
Model:
JD-ASF-1410、JD-ASF-1813、JD-ASF-2516
Intro:
◇ Electric oscillating knife head, strong power, high vibration frequency, up to 25,000 times per minute. ◇ The cutting machine drive system adopts imported linear guides, racks and gears, and the cutting precision fully reaches the zero error of the round-trip origin. ◇ The machine has functional heads: oscillating knife cutting head, round knife, V notch, V cut, presser wheel and drawing pens. It can cut asbestos gaskets, rubber gaskets, honeycomb paperboard, plastic corrugated board, plastic hollow board, gray board paper, composite material, rubber sheet, pearl cotton and EVA board. ◇ Programmable multi-axis motion controller, the stability and operability reach the leading technology level at home and abroad. ◇ The machine table is made of American imported fiberboard, which is breathable, durable and not easily deformed. ◇ Adopting the self-developed upper computer control system, that is, the humanized control interface of the learning, support remote teaching, remote maintenance, remote upgrade, and make customers use more peace of mind. ◇ Can be connected to any CAD software, widely used in the gasket industry, apparel industry, composite materials, luggage industry, automotive industry, advertising printing industry, decoration industry, furniture and other industries drawing and cutting. ◇ Optional loading rack and automatic feeding device.
Contacts:
18923737801(wechat)Click there to chat with me.
Product introduction Return to the list


Functional features: 1. Electric vibration knife and gun head, strong power, high vibration frequency, up to 25,000 times per minute.

2. The transmission system of the cutting machine adopts imported linear guide rail, rack and gear, and the cutting precision reaches zero error to and from the origin.

3. The machine has function head optional: vibration knife, round knife, V scissors, V knife, creasing wheel and drawing pen, etc.It can cut asbestos gasket, rubber gasket, honeycomb board, plastic corrugated board, plastic hollow board, grey board, composite material, rubber board, pearl cotton and EVA board etc.

 4. Programmable multi-axis motion controller, with stability and maneuverability reaching the leading technical level at home and abroad.

 5. The machine table is made of fiberboard imported from the United States, with good air permeability, durable and not easy to deform.

 6. Adopt the upper computer control system completely developed by ourselves, which is able to learn and operate humanized interface, and support remote teaching, remote maintenance and remote upgrade, so that customers can use more worry free.

7. Can be connected to any CAD software, widely used in gasket industry, clothing industry, composite materials, luggage industry, automobile industry, advertising and printing industry, decoration industry, furniture industry and other industries of drawing and cutting.

8. Optional loading rack and automatic feeding device.


Table of Technical Information on Intelligent feed   cutting machine

技术参数/型号

Technical information/model

JD-ASF-1410A

JD-ASF-1813A

JD-ASF-2516A

JD-ASF-2520A

工作特性

Operation properties

电脑操作与切割机同时进行,快速完成数据传输,可连续使用

Computer operation and cutting   machines can be used simultaneously for quick data transmission capable of   continuous operations

切割速度

Cutting speed

最快可达1500mm/s

Maxi 1500mm/s

切割厚度

Cutting Thickness

0.2-60mm

切割材料

Cut materials

可切割30mm以下的复合材料、皮料、布料、亚克力、珍珠棉和泡沫KT板等多种材料。

Corrugated materials, sponge and foam   board, lvory cardboard, gray paper, corrugated paper, plastic sheets,   composite materials and leather materials maximum cutting thickness at 30mm

笔数

Number of pens

8组不同的笔画:半刀、全刀、压轮设置、铣刀切割

8 different groups of strokes, half   blades, full blades and pressure wheel setup

定位方式

Positioning device

全自动摄像定位

Automatic camera positioning

固定纸的方式

Method for fixing paper

真空吸附

Vacuum absorption

切割精度

Cutting tolerance

±0.2mm

重复精度

Repeat accuracy

≦0.05mm

切割圆形直径

Minimum circle

≧5mm diameter

传输接口

Transmission interface

以太网口

Ethernet port

兼容软件格式

Format compatible

AI软件、Autocad、Coreldraw等软件都可以直接输出,无需转换,且带自动优化

Compatibility format AI software,   Autocad, Coreldraw and all box software

指令系统

Direcive system

HP-GL和GP-GL

HP-GL and GP-GL

数控面板

Digital control panel

液晶显示和触点按键

Liquid crystal display and contact   button

传动材料

Transmission materials

齿轮齿条传动

Gear-rack drive

工作电压和功率

Supply voltage

交流220V 380V ±10%,50HZ;整机功率6kw;保险丝规格6A

AC 220V 380V ±10%,50HZ

电机类型

Motor type

全进口三菱伺服电机

adopts servo motor

振动刀头

Vibration blade

振动刀头电机每分钟25000转

Vibration cutter head motor at   25000rpm

切割面积

Cutting area

1400mm*1000mm

1800mm*1300mm

2500mm*1600mm

2500mm*2010mm

外观尺寸

Overall dimension

2300*1700*1220mm

2700*2000*1220mm

3400*2300*1220mm

3400*2710*1220mm
