Flatbed Pen Cutter JD-A Series
Type:
Plotter
Model:
JD-A-0906、JD-A-1209、JD-A-1512
Intro:
Line drawing, drawing, text marking, half cutting, full cutting, one time. Meet the production target of less batch, more orders and more styles. The transmission system adopts imported linear guide rail with high speed, high precision, low sound and stable quality. Can be connected with any CAD sof
Contacts:
18923737801(wechat)Click there to chat with me.
Product introduction Return to the list

Function and Special Features


Jindex stepping plate cutting machine, can automatically feed action device. And operating software, can produce all the samples and samples, it can be used in clothing, shoes and bags and other industries, as well as compatible with all popular CAD systems. The high quality machine guarantees the extremely high accuracy and the speed, regardless of the cutting condition.

◇  Line drawing, drawing, text annotation, half knife cutting, full knife cutting, a complete. Meet the production target of less batch, more orders and more styles.

◇  The transmission system adopts imported linear guide rail, high speed, high precision, low sound, stable quality.

◇  Static board original imported parts from Japan, other parts and components also used a large number of imported products.

◇  The fastest cutting speed up to 1200mm/s.

◇  Standard I/O interface, in HP-GL format.

◇  Optional loading rack and automatic feeding device.

◇  Any CAD software can be connected, widely used in clothing, shoes, bags and handbags, laser knife mold drawing, lighting, advertising gifts, adhesive, color box packaging and other industries drawing and cutting.


Flatbed Pen Cutter JD-A Series Technical Parameters Standard Table

Technical Parameters/Model

JD-A-1209

JD-A-1509

JD-A-1512

Operating Characteristic

Computer operation and machine cutting can be performed simultaneously, as well data transmission can be completed quickly and used continuously.

Cutting Speed

Up to 1200mm/s

Cutting Thickness

≤2.0 MM

Cutting Material

Yellow thick cardboard, red cardboard, PVC board, white cardboard, chicken paper, fiber midsole and plastic board,etc.

Cutting Method

Multi-purpose knife holder, 4 sets of different strokes, half-knife, full-knife settings

Pen Type/Knife Type

Ordinary signature pen, oil pen, ball pen / Special steel knife

Fixed Way

Double-sided adhesive paste / vacuum adsorption / electrostatic adsorption

Mechanical Resolution

0.005 mm

Software Resolution

0. 025mm、0. 01mm、0. 1mm optional

Cutting Circular Diameter

≧2mm diameter

Transmission Interface

Standard parallel port, serial port

Format Compatible

AI software, Autocad, Coreldraw and all box design software can be directly output without conversion, with automatic optimization

Command System

HP-GL&GP-GL

CNC Panel

Liquid crystal display and contact buttons

Transmission Material

Linear guide, imported synchronous belt

 Voltage and Power

AC 220V  ± 10%, 50HZ;  Fuse Size 6A

Cutting Area

1200mm*900mm

1500mm*900mm

1500mm*1200mm

Appearance Size

1580x1330x920mm

1850x1330x920mm

1850x1610x920mm



Imported timing belt ensures safe and stable transmission

Synchronous gear accessories

Knife pen double head design automatic cutting conversion

Imported balanced linear guides ensure uninterrupted cutting and precise cutting profiles

User-friendly control panel

Connect to other CAD systems by importing HPGL format files
